OP1000 Barrier-Free Optical Turnstiles

$ 2,980.00$ 4,405.00

Clear

Description

As a state-of-the-art optical turnstile, OP1000 maintains a high-security level while remaining unobtrusive. It replaces the traditional physical barriers by utilizing active infrared beams to create an invisible electronic field between two pedestals. If there are any unauthorized entry attempts, an audible alarm will be triggered to alert security staff.

Data Sheet – OP1000 Series Turnstiles



FEATURES

  • Barrier-Free
  • SUS304 Stainless Steel Housing
  • Alarm Response
  • Bi-Directional Passage
  • LED pictograms for intuitive user experience
  • High throughput
  • High quality at an affordable price
  • Low power consumption
  • Wide range of accessories
  • Easy and simple installation process
  • Easy to maintain and monitor
  • Single-Lane or Multiple-Lane Configurations



Models

OP1000 Single lane optical turnstile
OP1011 Single lane optical turnstile (w/ controller and RFID reader)
OP1022 Single lane optical turnstile (w/ controller RFID, and fingerprint reader)
OP1200 Center Lane Expansion Module
OP1211 Center Lane Expansion Module (w/ controller and RFID reader)
OP1222 Center Lane Expansion Module (w/ controller RFID, and fingerprint reader)



DIMENSIONS

  • Length: 500mm /19.68 in
  • Width: 180mm / 7.08 in
  • Height: 1000mm / 39.37 in



SPECIFICATIONS

Power requirements AC 100 ~ 120V/200 ~ 240V, 50/60Hz
Working temperature -28°C~ 60°C
Working humidity 5%~80%
Working environment Indoor/outdoor (if sheltered)
Speed of throughput Maximum 30 persons/minute
Lane width (suggested) 600mm / 23.62 in
Footprint (of 2 cabinets with 600mm passage width) 500 x 960mm / 19.68 x 37.79 in
Dimensions L=500/19.68, W=180/7.08, H=1000/39.37
Dimensions with packing L=600/ 23.6, W=220/8.66, H=1100/43.5
Net weight 38kg / 83.7 lbs
Weight with packing 48kg / 105.8 lbs
LED indicator Yes
Cabinet material SUS304 stainless steel
Lid material SUS304 stainless steel
Security level Medium
Mean cycles between failure 2 million



INSTALLATION

Installation Services Available
See our portfolio of work Here

*Please note: Freight is not included and will be billed separately. Contact us for a quote.





Additional information

Weight 106 lbs
Dimensions 24 × 9 × 44 in
Selection

OP1000 Single lane optical turnstile, OP1011 Single lane optical turnstile (w/ controller and RFID reader), OP1022 Single lane optical turnstile (w/ controller RFID, and fingerprint reader), OP1200 Center Lane Expansion Module, OP1211 Center Lane Expansion Module (w/ controller and RFID reader), OP1222 Center Lane Expansion Module (w/ controller RFID, and fingerprint reader)
