BC-301 Bar Code Reader

$ 490.00

Description

The BC-301 Bar Code Reader uses inexpensive bar code cards and reads most common code formats, including Code 39, Interleaved 2 of 5, UPC/EAN and Codabar.
The readers are fully weatherproof and its tough shell is made of carbon-filled polycarbonate for extra durability. The bar code reader connects to the access control system via a simple Weigand interface.



Data Sheet – BC301 Bar Code Reader



FEATURES

  • Reads the most common bar code formats including Code 39, Interleaved 2 of 5, UPC/EAN, Codabar (use POL-C1CN Polaris-2 magnetic stripe cards or others)
  • The Readers are Fully Weatherproof and Its Tough Shell is Made of Carbon Filled Polycarbonate for Extra Durability
  • The Bar Code Reader Connects to EntraPASS Access Control System Via Weigand Interface



SPECIFICATIONS

External dimensions: 12.8 x 4.32 x 3.9cm
(5.05″H x 1.70″W x 1.54″T)

Weight: 0.170 kg (0.375 lbs)

Housing material: Carbon filled polycarbonate

Finish: Natural (Black)

Operating temperature: -30ºC to 70ºC (-22ºF to 150ºF)

Operating environment: Indoor and outdoor

Operating voltage: 5 VDC

Power consumption: 40mA

Cable type: 8 conductors plus drain, 24 AWG

Cable length: 1.83 meters (6 feet)

Certification: FCC, CE
BAR CODE

Maximum resolution: 5 mils (0.005″)

Wavelength: 950 nm

Scanning speed: 3 to 30 in/sec. with 7 mil bar code

Bar code center line: 1.14cm (0.450″) standard

Bar code symbologies: Code 39, Interleaved 2 of 5,
Codabar, UPC-A, UPC-B, BAN,
Code 11, Code 93, Code 128, MSI

Bar code decoding: Bi-directional, auto discriminating

Output: ABA track II emulation



WIRING
